SolarEngine 50W Mono-Crystalline Solar Panel

This 50W solar panel is a robust all-purpose module product ideal for roof top or ground mounted small sized off-grid solar power systems.
Product Advantage:
- Positive tolerance 0...+3%, increase the output performance
- Good for off-grid application(RV, cottage, remote site, boat)
- UV protection
- All weather protection
- Moisture protection
- Corrosive protection
- Strong aluminum frames to strengthen the load hold and to stand against high wind
- High transmittance low iron tempered glass with enhanced stiffness and impact resistance
Electrical characteristics:
| Rated Power |
50W |
| Tolerance |
±5% |
| Max. power voltage, Vm |
17.82V |
| Max. power current, Im |
2.81A |
| Open circuit voltage (Voc) |
21.96V |
| Open circuit current (Isc) |
3.17A |
| Cell efficiency |
17% |
| Max. system voltage |
1000VDC |
| Temp. Coefficient of rated power |
-0.48%/°C |
| Temp. Coefficient of Voc |
-0.347%/°C |
| Temp. Coefficient of Isc |
0.055%/°C |
| Operating Temperature |
-40°C ... +85°C |
| Mechanical Load |
5400Pa |
*Measured at standard test conditions: 25°C, AM1.5, 1000W/m2
Mechanical characteristics:
| Dimensions |
700x510x30mm (27.5 x 20 x 1.2 inch ) |
| Weight |
3.85kg (8.5 lbs) |
| Cable |
50cm cable with MC4 connector |
| Frame |
Anodized aluminum |
| Bypass diodes |
2 |
| Glass |
High Transmission Tempered Glass |
| Encapsulate |
EVA |
| Back sheet |
TPT |
Warranty:
1 year product warranty.
90% power output over 10 years
80% power output over 25 years
|
